    GRANADA

    CLAY ROOF TILES

    If the priority is aesthetics...

    The choice of roofs where aesthetics is the most important element… It adorns the roof of your dreams with its wide curved, top and side interlocking design. Creating the roof culture of Mediterranean civilizations, Granada Tile provides a unique beauty and privilege to the architecture of villa-type buildings. Produced with micro clay technology, Granada tile provides a long-lasting unique appearance with its smooth structure and strength value above the standards.

    Technical Features

    Dimensions (cm) 24x40,5 cm (±%2)
    Dimensions (inch) 7,87x15,94 inch (±%2)
    Use 15 pcs/m²
    Endurance 400 Kgf (±20kgf)
    Per 20' container 6144 pcs
    Per Pallet 256 pcs
    Granada
    • Strengths
    • Application
    • References
    • Accessories
    • Quality Certificates


    1- As the channels in the laying are completely closed, extra water tightness is provided.


    2- Its curved structure adds a perfect aesthetics to the roof. This is a feature not found in other roofing materials, so it is highly preferred in villas.


    3- Its smooth surface makes it difficult to hold dust and dirt.


    4- It is not possible to enter water through the nail hole.





     1. During laying, the distance between the first lath and the second lath is 30 cm, and the other lath spacing is 33.6 cm. However, in order to be sure, it is necessary to determine the lath spacing on site after the tile lands on the construction site.


     2. The first lath should be 4 cm and other laths should be 2.2 or 2.5 cm high.


     3. The Granada tile is placed from the left side of the fringe and from the bottom up by holding a string or a jig. After the vertical first row, the other rows are placed with the same system.


    4. The laying process should be done from right to left when viewed from the front. The thread at the bottom right of each tile should be well fitted into the groove of the next tile. The threads of the next tile in the top row should also be placed         in the grooves of the bottom row.


     5. The tiles coming to the inclined valley and ridge are properly cut and placed with the help of spiral. In valley streams, the tiles cut along the valley line must be glued with high strength adhesives to fix the parts.


     6. When tiles are laid on rafters roof covering (continuous covering such as wood or OSB), it is necessary to ventilate the bottom of the tiles. Deformation may occur on the lower surfaces of the tiles that are not ventilated due to condensation.       50 cm in cold roofs to provide ventilation under tiles. Vertical lathing process is done in intervals, and channelled insulating plate should be used in hot roofs. In order to complete the circulation of the air under the tile, an insulation tape open to     steam is used under the ridge.



























    Ventilating Tile.

    Ventilating Tile.

    Granada Ventilating Tile

    Granada Ventilating Tile
    Technical Features
    Dimensions (cm) 24x40cm (±%2)
    Dimensions (inch) 9,44x15,74inch (±%2)
    Weight 3100 gr

    Ventilating Systems

    Ventilating Systems

    Universal Ventilating

    Universal Ventilating

    Aerial Entry

    Aerial Entry

    Aerial Entry

    Aerial Entry
    Aerial Entry

    Eaves Tile

    Eaves Tile

    Left Eaves Tile

    Left Eaves Tile
    Technical Features
    Dimensions (cm) 16x18x41cm (±%2)
    Dimensions (inch) 6.29x7.08x16.14 inch (±%2)
    Weight 3300gr (±100gr)

    Right Eaves Tile

    Right Eaves Tile
    Technical Features
    Dimension (cm) 16x18x41cm (±%2)
    Dimension (inch) 6.29x7.08x16.14inch (±%2)
    Weight 3300gr (±100gr)

    Ridge Starter

    Ridge Starter

    Ridge Starter

    Ridge Starter
    Technical Features
    Dimension(cm) 24x43cm (±%2)
    Dimension(inch) 9.44x16.92inch (±%2)
    Weight 3850gr (±100gr)

    Ridge

    Ridge

    Right Ridge

    Right Ridge
    Technical Features
    Dimensions (cm) 23x43cm (±%2)
    Dimensions (inch) 9.05x16.92inch (±%2)
    Weight 3550gr (±100gr)
    Use 3 pcs/meter

    Left Ridge

    Left Ridge
    Technical Features
    Dimensions (cm) 22/26x43cm (±%2)
    Dimensions (inch) 8.66/10.23x16.92inch (±%2)
    Weight 3800gr (±100gr)
    use 3 pcs/meter

    3 Way Ridge

    3 Way Ridge

    3 Way Ridge - 2

    3 Way Ridge - 2
    Technical Features
    Dimensions (cm) 23x18,5x23 cm
    Dimensions (inch) 9.05x7.28x9.05 inch
    Weight 4755 gr

    3 Way Ridge - 3

    3 Way Ridge - 3
    Technical Features
    Dimensions (cm) 19x22x23cm
    Dimensions (inch) 7.48x8.66x9.05 inch
    Weight 5000gr
