MEGARON S
CONCRETE TILESIts narrow curvature and channel width, combined with its smooth surface
Its narrow curvature and channel width, combined with its smooth surface, add colour to the roofs with its design facilitating water discharge, special rounded cut and double layer painting technology.
Technical Features
| Dimensions (cm) | 33cm x 42 cm |
| Dimensions (inch) | 12.99inch x 16.53 inch |
| Weight | 4.2 kg (± %5) |
| Pallet/pcs | 252 pcs/Pallet |
| Use | 10 pcs/m² |
| Per 20 'container | 6144 pcs |
| Per Pallet | 256 pcs |
-
Strengths
-
Application
-
References
-
Accessories
-
Quality Certificates
1.) After vertical laths are made on the roof, horizontal lathing should be done, starting from the eaves with 34 cm (± 0.5cm tolerance) intervals before the tiles are laid, with the first lath being 5cm x5cm and the others 3cmx5cm.
2.) The tiles should start from the bottom of the eaves and be fixed with screws in the order shown below.
3.) Megaron tiles are not staggered. As stated below, each tile is interlocked and assembled.
4.) Since cut tile dust may cause dirt on the roof, it may require cleaning after application, it is recommended not to do tile cutting on the roof. The cut areas should be painted with touch-up paint.
5.) The use of a ventilation tile per 10 m2 in the roof slab is required for ventilation under the roof.
6.) Mortar should not be used in the installation of ridge mounting mortar and cut tiles. Dry ridge system should be used in ridge assembly.
Megaron S Ventilating Tile
Megaron S Ventilating Tile
| Technical Features | |
| Dimensions (cm) | 33x42 cm |
| Dimensions (inch) | 12.99x16.53 inch |
| Use | 1 Pcs./10 m2 |
| Weight | 6,3 Kg (+- %5) |
Megaron S Ridge
Megaron S Ridge
| Technical Features | |
| Dimensions (cm) | 40x23x20 cm |
| Dimensions (inch) | 15.74x9.05x7.87 inch |
| Use | 3 pcs/m2 |
| Weight | 3,9 Kg (+- %5) |
Megaron S Ridge Starter
megaron S Ridge Starter
| Technical Features | |
| Dimensions (cm) | 19x23x35 cm |
| Dimensions (inch) | 7.48x9.05x13.77 inch |
| Weight | 3,45 Kg (+- %5) |
Megaron S 3 Way Ridge
Megaron S 3 Way Ridge
| Technical Features | |
| Dimensions (cm) | 17x17x22 cm |
| Dimensions (inch) | 6.69x6.69x8.66 inch |
| Weight | 6,3 Kg (+- %5) |
Megaron S 4 Way Ridge
Megaron S 4 Way Ridge
| Technical Features | |
| Dimensions (cm) | 33x42 cm |
| Dimensions (inch) | 12.99x16.53 inch |
| Use | 1 Pcs/10m2 |
| Weight | 6,3/5,76 Kg (+- %5) |
Megaron S Eaves Tile
Megaron S Eaves Tile
| Technical Features | |
| Dimensions (cm) | 33x42 cm |
| Dimensions (inch) | 12.99x16.53 inch |
| Weight | 6,90 Kg (+- %5) |
