VALENSİYA
CLAY ROOF TILESFor the ones wishing all features together...
Valencia Tile adds an aesthetic appearance to roofs with its new design. Valencia Tile, whose waterproofing performance is developed, offers a long-lasting solution, especially in areas with heavy rainfall, with its wide channel structure. Produced with micro clay technology, Valencia tile offers a smooth surface and high strength, and offers alternative solutions to different architectural structures thanks to its design that allows it to be applied in different roof slopes and types.

-
Strengths
-
Application
-
References
-
Accessories
-
Quality Certificates
|
1. The first lath (eave lath) and the second lath spacing are 30 cm from the axis, and the other lath spacing is 33.6 cm. 2. However, in order to be sure, it is necessary to determine the lath spacing on site after the tile lands on the construction site. 3. First lath should be 4 cm and other laths should be 2.2 or 2.5 cm high. 4. The Valencia tile is placed from the left of the fringe and from the bottom up, by holding a rope or a jig. After the vertical first row, the other rows are placed with the same system. 5. The laying process should be done from right to left when viewed from the front. The thread at the bottom right of each tile should be well fitted into the groove of the next tile. The threads of the next tile in the top row should also be placed in the grooves of the bottom row. 6. When tiles are laid on rafters roof covering (continuous covering such as wood or OSB), it is necessary to ventilate the bottom of the tiles. Deformation may occur on the lower surfaces of the tiles that are not ventilated due to condensation. 50 cm in cold roofs to provide ventilation under tiles. vertical lathing process is done in intervals, and channelled insulating plate should be used in hot roofs. In order to complete the circulation of the air under the tile, an insulation tape open to steam is used under the ridge. |
Ventilating Tile.

Valensiya Ventilating Tile

Technical Features | |
Dimensions (cm) | 24x40cm (±%2) |
Dimensions (inch) | 9,44x15,74inch (±%2) |
Weight | 3100 gr |
Ventilating Systems

Universal Ventilating

Eaves Tile

Left Eaves Tile

Technical Features | |
Dimensions (cm) | 16x18x41cm (±%2) |
Dimensions (inch) | 6.29x7.08x16.14 inch (±%2) |
weight | 3300gr (±100gr) |
Right Eaves Tile

Technical Features | |
Dimensions (cm) | 16x18x41cm (±%2) |
Dimensions (inch) | 6.29x7.08x16.14inch (±%2) |
Weight | 3300gr (±100gr) |
Ridge Starter

Ridge Starter

Technical Features | |
Dimensions (cm) | 24x43cm (±%2) |
Dimensions (inch) | 9.44x16.92inch (±%2) |
Weight | 3850gr (±100gr) |
Ridge

Right Ridge

Technical Features | |
Dimensions (cm) | 23x43cm (±%2) |
Dimensions (inch) | 9.05x16.92inch (±%2) |
Weight | 3550gr (±100gr) |
Use | 3 pcs/meter |
Left Ridge

Technical Features | |
Dimensions (cm) | 22/26x43cm (±%2) |
Dimensions (inch) | 8.66/10.23x16.92inch (±%2) |
Weight | 3800gr (±100gr) |
Use | 3 pcs/meter |
3 Way Ridge

3 Way Ridge-2

Technical Features | |
Dimensions (cm) | 23x18,5x23 cm |
Dimensions (inch) | 9.05x7.28x9.05 inch |
Weight | 4755 gr |
3 Way Ridge - 3

Technical Features | |
Dimensions (cm) | 23x18,5x23 cm |
Dimensions (inch) | 9.05x7.28x9.05 inch |
Weight | 4755 gr |
